FKW-24KV Outdoor Ceramic Pole-Mounted Load Breaker Switch Rubber Isolator Load Breaker

FKW type Outdoor on load break switch (switch disconnector) contained in this list are destined to switch stub lines and ring main lines or transformers( It can be equipped with MV HRC fuse links as short circuit protection function) or for switching under on load conditions.
FKW type switch comply with IEC/IEEE and DVE-recommendation standards. Especially comply with DIN VDE 0670 part 3 and IEC publication IEC-60265, IEC-129

    Contact us
    Product Detail

    Description:

    Outdoor load break switch is used in outdoor 12/24/40.5kV three phase AC 50/60Hz power system, it composed of disconnect blade, arc extinguishing chamber and operating mechanism.

    It adopts the principle of compressed gas production and arc extinguishing, which has the advantages of simple structure, low maintenance, strong arc extinguishing ability, high fracture insulation level, and high reliability, reaching the level of similar foreign products.

    This switch is suitable for outdoor three-phase power distribution system with rated voltage below 12kV and rated frequency of 50Hz to meet the load current. In the open position, it can meet the isolation requirements specified for the isolating switch.

    Specification:

    Number of Pole
    		 3
    Place of Origin Zhejiang,China
    Brand Name SHUANGFENG
    Model Number FKW-12KV
    Type
    Load-break switches
    Material Ceramic
    Frequency 50Hz, 60Hz
    Application
    Industrial, electric power transmission
    Usage Outdoor
    Rated Voltage 12kv
    Function ON-OFF-ON
